66 Reserved 0 1 0 1 0 0 0 0
67 Reserved 1 0 0 1 0 1 0 0
68 Reserved 0 0 0 1 0 0 0 1
69 Reserved 1 0 0 0 1 1 1 0
70 Config38
- - - - - - - CRC
1 0 0 0 1 0 1 1
71 Reserved 0 1 1 0 1 1 0 0
72 Reserved 0 0 1 1 1 0 1 1
73 Reserved 0 1 0 1 1 0 1 0
74 Reserved 0 0 1 1 0 1 0 0
75 Reserved 1 0 0 1 0 1 0 1
76 Config44
- - - - - - RATE[1:0]
1 0 0 0 1 1 1 1
77 Config45
- - - - - - VDIFF_LAT MAX_CUR
0 1 0 0 0 0 0 1
78 Config46
- - - - WAKEUP[3:0]
1 0 1 0 0 1 0 1
79 Config47
OCP OLP OVP BOP COP LLP EEOTP IOTP
0 0 0 0 0 0 0 0
80 Config48
OCP_BLANK[3:0] OLP_BLANK[2:0] IOTP_SAMP
0 0 0 0 0 1 0 1
81 Config49
OCP_CNT[2:0] OCP_LAT OLP_CNT[2:0] OLP_LAT
1 0 1 0 1 0 1 0
82 Config50
OVP_CNT[2:0] OVP_LAT OVP_TYPE OVP_BLANK[2:0]
1 0 1 0 1 0 1 1
83 Config51
RESTART[5:0]
FAULT_SLO
W
FAULT_SHD
N
0 1 1 0 0 1 1 1
84 Config52
COP_THRES[6:0] COP_INT
0 0 1 0 0 0 0 0
85 Config53
BOP_INTEG[2:0] BOP_THRES[3:0] BOOST_ON
1 1 1 1 0 1 1 0
86 Config54
LLP_TIME[2:0]
BOP_RSTAR
T
- - - -
0 1 0 1 0 1 1 1
87 Config55
- - EOTP_FLP[2:0] EOTP_SLP[2:0]
0 1 1 0 0 1 1 0
88 Reserved 0 1 0 1 0 1 1 0
89 PLC_DIM
2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
0 1 1 1 1 1 1 1
90 Config58
SHUTDWN[3:0] LOW_SAT[2:0] DIM_TEMP
0 1 0 1 0 0 1 1
Add Name 7 6 5 4 3 2 1 0
