AN368
74 AN368REV2
91 Config59
eOTP[4:0] HI_SAT[2:0]
1 1 1 1 0 1 0 0
92 Config60
- PLC - CS_DELAY[2:0] - -
1 0 1 1 1 1 1 1
93 Config61
DITNODIM DITLEVEL[1:0] DITCHAN - - - -
0 0 0 0 1 0 1 1
94 Config62
CH2_OFF[2:0] CH1_OFF[2:0] BST_LLP[1:0]
1 1 1 1 0 1 0 1
95 Reserved 0 0 0 0 0 0 0 1
96 Reserved 0 0 0 0 0 0 0 0
97 Reserved 0 0 0 0 0 0 0 0
98 Reserved 0 0 0 0 0 0 0 0
99 Reserved 0 0 0 0 0 0 0 0
100 Reserved 0 0 0 0 0 0 0 0
101 Reserved 0 0 0 0 0 0 0 0
102 CRC_TAG
2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
0 0 0 0 0 0 0 0
103 Reserved 1 0 1 0 0 0 0 0
104 Reserved 0 0 0 0 0 0 0 0
105 Reserved 1 0 0 0 0 0 0 0
106 Reserved 0 0 0 0 0 0 0 0
107 Reserved 0 0 0 0 0 0 0 0
108 Reserved 1 0 0 0 0 0 0 0
109 Reserved 0 1 1 1 1 1 0 0
110 Reserved 0 0 0 0 0 0 0 0
111 Reserved 0 0 0 0 0 0 0 0
112 Reserved 0 0 0 0 0 0 0 0
113 Reserved 0 0 1 0 0 0 0 0
114 Reserved 0 0 0 1 0 1 0 0
115 Reserved 1 0 0 0 0 0 0 0
116 Reserved 0 0 0 0 0 0 0 0
117 Reserved 0 0 0 0 0 0 0 0
118 Reserved 0 0 0 0 0 0 0 0
119 CH1_CAL3A
SET_3A - CH1_CAL3A[5:0]
0 0 0 0 0 0 0 0
120 CH2_CAL3A
- - CH2_CAL3A[5:0]
0 0 0 0 0 0 0 0
121 CRC_MTAG3A
2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
0 0 0 0 0 0 0 0
122 CH1_CAL3B
SET_3B - CH1_CAL3B[5:0]
0 0 0 0 0 0 0 0
Add Name 7 6 5 4 3 2 1 0
