DGPI(L)−...−AI F
Festo DGPI(L)−...−AIF 0409a English
37
Electric
Measuring system Magnetostrictive, contactless, absolute measuring
Protection class (measuring system incl.
housing and connections) IP65
(with correctly fitted connector socket with cable)
Electrical connection 6−pin round plug as per DIN 45322
Interface CAN as per ISO/DIS 11898
Data protocol / transmission rate SPC−AIF / 1 Mbit/s
Linearity < ± 0.02 % F.S. (min. ± 50 ìm)
Resolution
Ţ 0.01 mm
Power supply 24 V DC (+ 20 / − 15 %)
Current consumption (start/stop) 90 mA typ.
Temperature coefficient < 15 ppm / °C
EMC resistance (with earthed cylinder) DIN EN 61000−6−2 / DIN EN 61000−6−3
