Page 24

DGPI(L)−...−AI F
Festo DGPI(L)−...−AIF 0409a English
24
6
Fitting
Fitting mechanical components
S
Avoid damaging the band system.
Damage to the band system can cause
leakage and reduce the efficiency of the
DGPI(L)−...Ă.
S
Make sure that the drive is fitted free of
mechanical stress and distortion.
If required, use the profile fastening here
(centre support) type MUP−...Ă.
40
32
25
DGPI(L) −
1000
1500
2000
2500
3000
0
500
1000
F
F
F
l
l
F [N]
l [mm]
dia. 80
dia. 63
dia. 50
F [N]
l [mm]
100
1000
10000
100000
500
1000
1500
2000
2500
3000
Fig. 7: Necessary gaps between supports
Fig. 5
Fig. 6
