DGPI(L)−...−AI F
Festo DGPI(L)−...−AIF 0409a English
36
13
Technical specifications
Pneumatic, mechanical
Size
25
32
40
50
63
Medium
Compressed air, dried, filtered (5
ìm), non−lubricated
Design
Double−acting pneumatic cylinder without piston rod with rigid piston−
slide connection and integrated measuring system
Operating pressure
(min. ... max.)
2 ... 8 bar
1.5 ... 8 bar
Temperature
min. −10 ... max. + 60 °C
Mounting position
As desired
End positioning
cushioning
Pneumatic, adjustable
Cushioning length
18 mm
20 mm
30 mm
Stroke reduction per end
position
25 mm
35 mm
Stroke force
(theor., at 6 bar)
295 N
483 N
754 N
1178 N
1870 N
Air consumption
(theor.,Ăper 10 mm stroke)
0.034 Nl
0.056 Nl
0.088 Nl
0.137 Nl
0.218 Nl
Leakage when new
max. 10 l/h (at 6 bar)
max. 20 l/h (at 6 bar)
Permitted work load
component vertical to
cylinder axis and
permitted static slide
tilting torques
Depends on type, speed and loading;
can be calculated with catalogue specifications
Materials
Cylinder profile, driver, end cover:
Al anodized/painted
Seals, sealing band:
NBR/PU
Guide band, reversing roller, dirt wiper:
POM
Guide rail:
St (bearing guide)
