Repairs
S
Make sure that the DGPI(L)−... is overhauled only by our repair service.
The repair procedures require very fine adjustments.
11
Accessories
Designation
Type
For fastening the DGPI(L)−...:
Foot fastening
Profile fastening (centre support)
HP−...
MUP−...
For fastening the work load on the slide:
Centring pins / centring sleeves
Central fastening
Sliding blocks (L for slide)
ZBS−... / ZBH−...
SLZZ−...
NST(L)−...
Groove cover rail
ABP−...
Shock absorber
Shock absorber, any position
YSR−...−C / YSRW−...
KYP−...
Connecting kit dovetail diagonally on slide
Connecting kit dovetail longitudinal on slide / on cover
HMAV (for HMP)
HMSV (for SLT)
HAPB / HMVA
Cross connecting kit for slide
HMVK−...
Connecting bracket for profile system
HMBV
Power bridge
AK−...
Grease gun with pinpoint nozzle
Greases: see chapter Maintenance"
