Installation Instructions
If you need further assistance, or find that you are missing any parts, please contact the dealer from which you purchased this product.
We hope you enjoy your fixture!
* Hubbardton Forge will not be liable for injury or damage caused by improper installation, lamping or use of this fixture.
To Install Glass
(Figures 3-5)
(Continued)
4. Tilt glass (K) over bulb and fasten round block (J) to
fixture assembly (A) using the thumb screw (N)
(Figure 5).
5. Restore electricity at main breaker.
B274
Pluto Outdoor Sconce 306603
Page 3 of 3
J
O
K
(Figure 5)
N
A
