Assembly & Installation Instructions
A122
For Compass Chandelier 19-453010 & 19-453610
Page 3 of 3 _
Hand-Forged, Vermont-Made Lighting and Accessories
P.O. Box 827, 154 Route 30 South, Castleton, Vermont 05735 19895 Rev A
(Figure 4)
To Install Diffuser Glass (Figure 4)
Component Parts
P Threaded Ball (4)
R Diffuser Glass (2)
S Threaded Stud (4)
1. Slip diffuser glass (R) over threaded stud (S).
2. Install threaded ball (P) on to threaded stud (S) until
snug against diffuser glass (R). Be careful not to over
tighten.
3. Restore electricity at main breaker.
If you need further assistance, or find that you are missing any parts, please contact the dealer from which you purchased
this product. We hope you enjoy your fixture!
* Hubbardton Forge will not be liable for injury or damage caused by improper installation, lamping or use of this fixture.
