Assembly & Installation Instructions
A120
For Exos Wave Five-Light Pendant 13-7545 Page 3 of 3
Hand-Forged, Vermont-Made Lighting and Accessories
P.O. Box 827, 154 Route 30 South, Castleton, Vermont 05735 19890 Rev A
To Install Glass
(Figure 5)
Component Parts
O Metal Glass Clip (10)
P Glass
Frame (5)
(Figure 5)
Q Bulb (5)
R Bulb Shield (5)
S Glass
(10)
1. Install light bulb (Q). Be careful not to touch bulb
with bare hands. Oil from the hands will
dramatically reduce bulb life.
2. Thread bulb shield (R) onto socket. Future bulb
changes may be accomplished by snapping glass
bulb shield on and off rather than unthreading the
holder.
3. Turn glass frame (P) to make glass installation
easier.
4. Mount metal glass clip (O) into notches on glass
frame (P).
5. Slide one side of glass (S) into slots in glass
frame (P).
6. Slide other side of glass (S) into glass frame (P).
7. Align the glass until it protrudes equal amounts on
both sides of fixture.
8. Turn glass frame (P) to desired angle.
If you need further assistance, or find that you are missing any parts, please contact the dealer from which you purchased
this product. We hope you enjoy your fixture!
* Hubbardton Forge will not be liable for injury or damage caused by improper installation, lamping or use of this fixture.
