Assembly & Installation Instructions
A339
Moreau Six Light Pendant 136555 Page 1 of 4
Hand-Forged, Vermont-Made Lighting and Accessories
154 Route 30 South, Castleton, Vermont 05735 28332
Attach Fixture Pipes (Figure 1)
Component Parts
A Fixture Pipe (2)
B Fixture Coupling (2)
1. Carefully unpack the fixture from the carton.
2. Carefully thread fixture pipes (A) over fixture
wires.
3. Apply a drop of the supplied thread locking
compound to the internal threads of the fixture
couplings (B) and screw fixture pipes (A) into
fixture, being careful not to twist the wires.
Note: Application of the thread locking compound
is necessary to prevent the stem from loosening
during regular maintenance and cleaning of the
fixture. Be certain to apply the compound.
4. See instructions below to complete the installation.
Assemble Canopy Pipes to Ceiling Bracket (Figure 2)
Component Parts
C Hex Nipple (2)
D Lock Washer (2)
E Ceiling Bracket
F Canopy Pipes (2)
1. Insert threaded end of hex nipple (C) down through lock
washer (D), ceiling bracket (E) and into swivel at the end of
canopy pipe (F).
Note: Ceiling bracket should be oriented with the threaded
studs point down.
2. Tighten securely being sure the notches in the swivels are
aligned.
(continued)
CAUTION: FAILURE TO INSTALL THIS FIXTURE PROPERLY MAY RESULT IN SERIOUS PERSONAL
INJURY OR DEATH AND PROPERTY DAMAGE. We recommend installation by a licensed electrician.
This product must be installed in accordance with applicable installation code(s), by a person familiar with the
construction and operation of the product and the hazards involved.*
Caution: Do not exceed maximum wattage noted on fixture. Use only recommended bulbs with fixture.
(Figure 1)
(Figure 1)
(Figure 2)
