Chapter 5: Port Configuration
70 Section I: Using the Menus Interface
Displaying the Port Parameters
To display the parameter settings for the ports on the switch, perform the
following procedure:
1. From the Main Menu, type B to select Basic Switch Configuration.
The Basic Switch Configuration Menu is shown in Figure 4 on page
32.
2. From the Basic Switch Configuration Menu, type P to select Port
Configuration.
The Port Configuration Menu is shown in Figure 17.
Figure 17. Port Configuration Menu
AT-9000/24 Local Management System
Basic Switch Configuration -> Port Configuration Menu
Back Pressure: Disabled
Port
Trunk Type Link Status Mode Flow Ctrl
---- ----- ------ ---- ------ ------------ ---------
1 --- 1000TX Up Enabled Auto Enabled
2 --- 1000TX Up Enabled Auto Enabled
3 --- 1000TX Up Enabled Auto Enabled
4 --- 1000TX Up Enabled Auto Enabled
5 --- 1000TX Up Enabled Auto Enabled
6 --- 1000TX Down Enabled Auto Enabled
7 --- 1000TX Up Enabled Auto Enabled
8 --- 1000TX Down Enabled Auto Enabled
9 --- 1000TX Up Enabled Auto Enabled
10 --- 1000TX Up Enabled Auto Enabled
11 --- 1000TX Up Enabled Auto Enabled
12 --- 1000TX Up Enabled Auto Enabled
----------------------- ------------------------------------
[N]ext Page
Set [S]tatus Set [F]low Control
[P]revious Page Set [M]ode Set [B]ack Pressure
[Q]uit to previous menu
Command>
