AT-S84 Management Software User’s Guide
Section II: Web Browser Interface 233
Viewing and Configuring a Single Port
The procedure in this section allows you to view or configure the
parameter settings of one port on the switch. To view and configure the
parameter settings for more than one port at a time, refer to “Viewing and
Configuring Multiple Ports” on page 230.
To view or configure the parameter settings of a single port, perform the
following procedure:
1. On the home page, in the front panel image, click the port that you
want to configure.
A sample Configuration of Port page is shown in Figure 68.
Figure 68. Configuration of Port Page
2. Adjust the following port settings as needed. Not all parameters are
adjustable.
Port Type
The port type. The port type is 1000TX for 10/100/1000Base-T twisted
pair ports and 1000BaseF for an optional SFP fiber optic port.
Trunk ID
The trunk group number. A number in this column indicates that the
