Chapter 2: Basic Switch Parameters
20
Configuring the IP Address, Subnet Mask, and Gateway Address
Warning
Be sure to record the switch’s IP address in a safe place. When you
change the switch’s IP address you lose your connection. Because
the AT-FS750/48 Fast Ethernet switch does not have a console port,
your only means of managing the switch is through a web browser,
which requires that you have the switch’s IP address.
To configure the IP settings, perform the following procedure:
1. From the main menu, select System > IP Setup.
The IP Setup page is shown in Figure 2.
Figure 2. IP Setup Page
2. From the VLAN ID list, select the VLAN you want the switch to be a
part of.
Note
The default VLAN is 1. To create more VLANs, refer to Chapter 7,
”VLANs” on page 63.
3. In the IP Address field, enter an IP address for the switch.
4. In the Network Mask field, enter an IP address for the subnet mask.
5. In the Default Gateway field, enter the IP address of the default
gateway.
6. Click OK.
The settings are immediately implemented and you lose your
connection to the switch.
