Chapter 2: Installing the Hardware
44
Installing the Switches in an Equipment Rack
Note
Installing a stack on a table or desktop is not recommended
because it may create a hazardous work area.
Perform the following procedure to install the switches in a standard
19-inch rack:
1. Place the switch upside down on a level, secure surface.
2. Using a flat-head screwdriver, remove the snap-on plastic feet from
the bottom of the switch, as shown in Figure 15.
Figure 15. Removing the Feet
3. Turn the switch over.
4. Attach a rack-mount bracket to one side of the switch using four of the
screws that come with the switch, as shown in Figure 16.
Figure 16. Attaching Rack-Mount Brackets
