AT-S63 Management Software Menus User’s Guide
Section VI: Virtual LANs 505
Displaying the GIP Connected Ports Ring
To display the GIP connected ports ring, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 170 on page 470.
2. From the VLAN Configuration menu, type 6 to select Configure GARP-
GVRP.
The GARP-GVRP menu is shown in Figure 179 on page 492.
3. From the GARP-GVRP menu, type O to select Other GVRP
Parameters menu.
The Other GARP Parameters menu is shown in Figure 183 on page
498.
4. From the Other GARP Port Parameters menu, type 3 to select Display
GIP Connected Ports Ring.
The GIP Connected Ports Ring menu is shown in Figure 187.
Figure 187. GIP Connected Ports Ring Menu
The GIP Connected Ports Ring menu displays the following
information:
GARP Application
Identifies the GARP application, that is, “GVRP.”
GIP Context ID
A number assigned to the instance for the GIP context.
Allied Telesis AT-9424T/SP - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2009
GIP Connected Ports Ring
GARP Application: GVRP
GIP Context ID: 0, STP ID: 0
------------------------------------------------------
4 -> 12 -> 18
U - Update Display
R - Return to Previous Menu
Enter your selection?
