Displaying the MSTP Port Configuration
To display the MSTP port configuration, perform the following procedure:
1. From the Main Menu, type 3 to select Spanning Tree Configuration.
The Spanning Tree Configuration menu is shown in Figure 151 on
page 416.
2. From the Spanning Tree Configuration menu, type 3 to select
Configure Active Protocol.
The MSTP Configuration menu is shown in Figure 161 on page 439.
3. From the MSTP Configuration menu, type P to select MSTP Port
Parameters.
The MSTP Port Parameters menu is shown in Figure 165 on page
456.
4. From the MSTP Port Parameters menu, type 3 to select Display MSTP
Port Configuration.
The Display MSTP Port Configuration menu is shown in Figure 168.
Figure 168. Display MSTP Port Configuration Menu
Allied Telesis AT-9424T/SP - AT-S63
Marketing
User: Manager
11:20:02 02-Mar-2009
Display MSTP Port Configuration
|
Cost
|
Port | Edge-Port |Point-to-Point | External Internal|Priority
--------------------------------------------------------------
1
Yes
Auto-Detect
200000
Auto
128
2
Yes
Auto-Detect
200000
Auto
128
3
Yes
Auto-Detect
200000
Auto
128
4
Yes
Auto-Detect
200000
Auto
128
5
Yes
Auto-Detect
200000
Auto
128
6
Yes
Auto-Detect
200000
Auto
128
7
Yes
Auto-Detect
200000
Auto
128
8
Yes
Auto-Detect
200000
Auto
128
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
