Chapter 19: MLD Snooping
306 Section III: Snooping Protocols
Displaying a List of Host Nodes
You can use the AT-S63 Management Software to display a list of the
multicast groups on a switch, as well as the host nodes. To display the list,
perform the following procedure:
1. From the Main Menu, type 6 to select Advanced Configuration.
The Advanced Configuration menu is shown in Figure 117 on page
292
2. From the Advanced Configuration menu, type 3 to select MLD
Snooping Configuration.
The MLD Snooping Configuration menu is shown in Figure 121 on
page 302.
3. From the MLD Snooping Configuration menu, type 6 to select View
MLD Multicast Hosts List.
The View MLD Multicast Host List menu is shown in Figure 122.
Figure 122. View MLD Multicast Hosts List Menu
The View MLD Multicast Hosts List menu displays a table with the
following columns of information:
Multicast Group
The multicast address of the group.
VLAN
The VID of the VLAN where the port is an untagged member.
Port/Trunk
The port on the switch where the host node is connected. If the host
Allied Telesis AT-9424T/SP - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2009
View MLD Multicast Hosts List
Number of MLD Multicast Groups: 1
VLAN Port/ Exp.
MulticastGroup ID TrunkID HostIP Time
--------------------------------------------------------------------------------------------
33:33:00:00:00:ab
1 6 fe80:0000:0000:0000:0208:74ff:feff:bf08 21
U - Update Display
R - Return to Previous Menu
Enter your selection?
