Chapter 15: Quality of Service
272 Section II: Advanced Operations
Displaying
Policies
To display policies, perform the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
2. From the Security and Services menu, type 6 to select Quality of
Service.
The Quality of Service (QoS) menu is shown in Figure 88 on page 248.
3. From the Quality of Service (QoS) menu, type 3 to select Policy
Configuration.
The Policy Configuration menu is shown in Figure 101 on page 267.
4. From the Policy Configuration menu, type 4 to select Show Policies.
The Show Policies menu is shown in Figure 104.
Figure 104. Show Policies Menu
The Show Policies menu provides the following information:
ID
The policy’s ID number.
Description
A description of the policy.
Active
The status of the policy. A policy that is assigned to one or more ports
is deemed active while a policy that is not assigned to any ports is
deemed inactive.
Allied Telesis AT-9424T/SP - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2009
Show Policies
Number of Policies: 4
ID
Description Active
------------------------------------------------
0
P1-4 database No
1 Main video Yes
2 Dev eng Yes
3 Alt video Yes
D - Display Policy Detail
U - Update Display
R - Return to Previous Menu
Enter your selection?
