AlliedView™-EMS 4.0.2 DEVICE MANAGER USER’S GUIDE Page 99 of 124
Request Buckets
The number of values which you asked the RMON agent to store.
Granted Buckets
The number of values the RMON agent allows you to store.
Sampling Interval
The time interval at which the RMON agent collects data.
Status
The status of the control entry.
Owner
The owner (creator) of the control entry.
7.3.3.2 Select Button
: changes the control entry displayed in the History window. To change the control entry
displayed, select an entry in the table, then click the Select button. Data collected by the
selected entry is displayed on other tabs thereafter.
Note - To display changes to the current entry, or to display a new entry with the same
index number as a previously removed entry, be sure to select the current entry.
Otherwise, the changes will not take effect on the other tabs.
7.3.3.3 Add Button
: adds a new entry to the RMON History control table. When you click this button, the
Add Control Table Entry dialog box appears. Enter the following parameters, then click OK
to create an entry.
Index
The index number used to identify this entry.
Data Source
The index of the interface on which the RMON agent collects data.
Request Buckets
The number of values which you want the RMON agent to store.
Sampling Interval
The interval at which the RMON agent retrieves data.
Owner
The creator (owner) of this entry.
