AlliedView™-EMS 4.0.2 DEVICE MANAGER USER’S GUIDE Page 72 of 124
6.4.1 Checkbox Column
The first (leftmost) column shows whether or not the variable can be changed (i.e. the
variable supports the SNMP Set operation). If a checkbox is displayed in the column,
the variable's value can be changed.
When you change several variables, set the new values in the Value column and then check
all corresponding boxes. Device Manager sends new values for selected variables in a batch.
6.4.2 MIB Variable Column
MIB variable names are displayed.
6.4.3 MIB Value Column
The value of the variable is displayed. If the variable has write access (and a checkbox
is displayed in the first column), this field is editable. To change the MIB value, change the
value and check the box and then click the Set MIB Value button. If the variable takes a value
from a fixed set of options, this field works as a pull down listbox. For such a variable,
clicking this field shows the listbox.
The value in this field is the one at the time when this tab is opened. The value in this
column is not updated automatically. If you want to see the latest value, use the Get MIB
Value button or switch to the Table tab.
Note - SNMPv3: Depending on the READ VIEW access settings of the User Account Name
used, there is a possibility that Device Manager may not be able to access some MIB values.
When this happens, the table will display a blank cell for those MIB values.
6.4.4 Select All Button
: checks all variables that can be changed.
6.4.5 Clear Button
: unchecks all variables that can be changed.
6.4.6 Reverse Button
: Flips the states of all checkboxes, that is, unchecks all variables currently checked,
and checks all variables currently not checked.
6.4.7 Get MIB Value Button
: Updates the MIB Value fields of the selected variables. To select a variable, click the MIB
Variable field of the target variable.
