AlliedView™-EMS 4.0.2 DEVICE MANAGER USER’S GUIDE Page 37 of 124
Privacy Password
If the Security Level is "Auth / Priv", you need to specify a Privacy Password.
Make sure to set the Privacy Password to be the same as what is configured
on the target device.
Trap Options
Version
This drop down list allows you to select the SNMP trap version to be used
in receiving traps.
Note - Device Manager will only accept "v3" trap version if SNMP version in the
SNMP Options panel is also set to "v3".
Note - Device Manager will only be able to process and display SNMP v3 traps
received from the currently connected device.
Enable 'Trap' operation
To receive traps from a target host's SNMP agent, check this box.
Note - If SNMPc, HP OpenView or Tivoli NetView is running, Device Manager
will not receive any traps. This is because the traps are being intercepted by the
network management application and will never reach Device Manager.
v1/v2c Trap Community Name
Specify the community string that will be used for receiving SNMP v1 or v2c traps.
The default string is "public".
Polling options
Settings
This button opens the Polling Options dialog box, in which you can change
the polling interval and retry parameters.
Polling Options dialog box
