Chapter 1: Overview
36
SD Card Slot
All of the x610 Series Switches have an SD card slot for storing
configuration files and AlliedWare Plus
Operating System Software image
files on an SD card (or SDHC card). See Figure 11.
SD
BUSY READY FAULT
Figure 11. SD Card Slot
An SD card, shown in Figure 12, can make it easier for you to upgrade the
files on a switch or transfer files between x610 switches.
1319
SD Memory Card
LOCK
Figure 12. SD Card
Note
An SD card is not required for normal operations of the switch.
To insert an SD card, position it so that the manufacturer’s brand label is
facing up and press it into the slot until it is flush with the front of the
chassis. To remove the SD card, gently press and release the card. The
SD card will then pop out so you can grasp it with your fingers.
For information on how to transfer files to and from a SD card, refer to the
AlliedWare Plus
Operating System Software Reference Guide.
