131
Appendix A
Technical Specifications
The Technical Specifications for the 8100 Series Stacking Switches are
contained in this section. The specification categories are:
 ”Physical Specifications” on page 131
 ”Environmental Specifications” on page 132
 ”Power Specifications” on page 133
 ”Certifications” on page 134
 ”RJ-45 Twisted Pair Port Pinouts” on page 134
 ”Fiber Optic Port Specifications” on page 136
 ”RJ-45 Style Serial Console Port Pinouts” on page 138
 ”Stacking Port Pinouts” on page 139
Note
For the technical specifications for the non-stacking 8100L Series
switches, refer to the Stand-alone Switch Installation Guide for
8100L and 8100S Series Switches.
Physical Specifications
Dimensions (H x W x D)
Table 17. Product Dimensions
AT-8100S/24C 4.4 cm x 33.0 cm x 20.3 cm
(1.7 in. x 13.0 in. x 8.1 in.)
AT-8100S/24
AT-8100S/24F-LC
AT-8100S/16F8-SC
AT-8100S/16F8-LC 4.4 cm x 44.1 cm x 29.1 cm
(1.7 in. x 17.3 in. x 11.5 in.)
AT-8100S/24POE 4.4 cm x 44.1 cm x 32.2 cm
(1.7 in. x 17.3 in. x 12.7 in.)
