LTPH-UM-1031-03, Issue 3 Monitoring System Activity and Performance
H4TU-C-319 List 1 September 12, 2003 33
Figure 20. H4TU-C HDSL (Loop 1/Loop 2) 25-Hour Performance History
Figure 21 shows statistics for the HDSL4 interface at the H4TU-C. This screen reports 1-day, 1-hour, and
15-minute statistics. Refer to Table 10 on page 34 for descriptions of the kinds of errors reported on this screen.
Figure 21. H4TU-C HDSL (Loop 1/Loop 2) Current Statistics
Monitor Performance Event Log Config Inventory Report Rlogon Help
H4TU-C HDSL 25-Hour History (Page 1 of 9) LP1/LP2
-----------------------------------------------------------------------------
Time CV ES SES UAS LOSWS
*06:45 0/0 0/0 0/0 0/0 0/0
*07:00 0/0 0/0 0/0 0/0 0/0
*07:15 0/0 0/0 0/0 0/0 0/0
*07:30 0/0 0/0 0/0 0/0 0/0
07:45 0/0 0/0 0/0 0/0 0/0
08:00 0/0 0/0 0/0 0/0 0/0
08:15 0/0 0/0 0/0 0/0 0/0
08:30 0/0 0/0 0/0 0/0 0/0
08:45 0/0 0/0 0/0 0/0 0/0
09:00 0/0 0/0 0/0 0/0 0/0
09:15 0/0 0/0 0/0 0/0 0/0
09:30 0/0 0/0 0/0 0/0 0/0
Press: (N)ext Page, (P)revious Page, C(l)ear History
------------------------------------------------------------------------------
Use to cycle through Interface : H4TU-C HDSL
choices and to view Statistics : 25-Hour History
ID: xxxx--xxxx--xxxx--xxxx 02/01/2002 12:30:01 H4TU-C System: OK ___
Monitor Performance Event Log Config Inventory Report Rlogon Help
H4TU-C HDSL Current Statistics LP1/LP2
-----------------------------------------------------------------------------
1 Day 1 Hour 15 Min
Start 05:57 07:00 07:30
CV 0/0 0/0 0/0
ES 0/0 0/0 0/0
SES 0/0 0/0 0/0
UAS 0/0 0/0 0/0
LOSWS 0/0 0/0 0/0
Margin(dB) LA(dB) INSL(dB)
Hi 16/17
Cur 14/16 0/0 0/0
Low 13/13
Press: C(l)ear Current Statistics
------------------------------------------------------------------------------
Use to cycle through Interface : H4TU-C HDSL
choices and to view Statistics : Current
ID: xxxx--xxxx--xxxx--xxxx 02/01/2002 12:30:01 H4TU-C System: OK ___
