Monitoring System Activity and Performance LTPH-UM-1031-03, Issue 3
30 September 12, 2003 H4TU-C-319 List 1
Examples of current statistics screens are shown below. Figure 16 and Figure 17 show statistics for the DS1
interface at the remote unit and line unit, respectively. These screens report 1-day, 1-hour, and 15-minute statistics.
Refer to
Table 9 on page 31 for descriptions of the kinds of errors reported on these screens.
Figure 16. H4TU-R DS1 Current Statistics
Figure 17. H4TU-C DS1 Current Statistics
Monitor Performance Event Log Config Inventory Report Rlogon Help
H4TU-R DS1 Current Statistics
-----------------------------------------------------------------------------
1 Day 1 Hour 15 Min
Start 05:57 07:00 07:00
CV-L 0 0 0
ES-L 0 0 0
SES-L 0 0 0
UAS-L 0 0 0
CV-P 0 0 0
ES-P 0 0 0
SES-P 0 0 0
UAS-P 0 0 0
PRM-NE No PRM Detected
PRM-FE No PRM Detected
B8ZSS 0 0 0
MSEC 0 0 0
Press: C(l)ear Current Statistics
------------------------------------------------------------------------------
Use to cycle through Interface : H4TU-R DS1
choices and to view Statistics : Current
ID: xxxx--xxxx--xxxx--xxxx 02/01/2002 12:30:01 H4TU-C System: OK ___
Monitor Performance Event Log Config Inventory Report Rlogon Help
H4TU-C DS1 Current Statistics
-----------------------------------------------------------------------------
1 Day 1 Hour 15 Min
Start 05:57 07:00 07:00
CV-L 0 0 0
ES-L 0 0 0
SES-L 0 0 0
UAS-L 0 0 0
CV-P 0 0 0
ES-P 0 0 0
SES-P 0 0 0
UAS-P 4242 476 476
B8ZSS 0 0 0
MSEC 4242 476 476
Press: C(l)ear Current Statistics
------------------------------------------------------------------------------
Use to cycle through Interface : H4TU-C DS1
choices and to view Statistics : Current
ID: xxxx--xxxx—-xxxx--xxxx 02/01/2002 12:30:01 H4TU-C System: OK ___
