English - 19
English
3D Basics
Network Connection - Wired
There are three main ways to connect your TV to your network using cable, depending
on your network setup. They are illustrated starting below:
The Modem
Port on the Wall
Modem Cable (Not Supplied) LAN Cable (Not Supplied)
One Connect
External Modem
(ADSL / VDSL / Cable TV)
The Modem
Port on the Wall
One Connect
Modem Cable
(Not Supplied) LAN Cable
(Not Supplied)
LAN Cable
(Not Supplied)
External Modem
(ADSL / VDSL / Cable TV)
IP Router that has
a DHCP Server
One Connect The LAN Port
on the Wall
LAN Cable (Not Supplied)
✎ The TV does not support network speeds less than or equal to 10Mbps.
✎ Use Cat 7 cable for the connection.
3D Active Glasses
Features
Samsung's SSG-3570CR 3D glasses enable you to view 3D images on your 3D TV.
The Samsung 3D glasses communicate with Samsung 3D TVs via the 2.4GHz RF
band.
✎ The Samsung 3D glasses are only compatible with Samsung D, E, and F series
3D TV's that are released 2011 to 2013. These 3D glasses cannot be connected
to other Bluetooth devices.
Parts
Nose pad
pairing button
Liquid-crystal shutter
The nose pads are adjustable.
✎ To wear the 3D glasses over eyeglasses, detach the nose pad from the 3D
glasses.
✎ For details on how to attach or detach the glasses' Nose pad, refer to the separate
3D glasses manual.
