Y1-03-0211 Rev D
88
NOTE: The SRM message transmission is automatically repeated every 180 seconds until
the [Stop] button has been pressed.
Each SRM Message that is sent out every 180 seconds contains updated navigation
information of own vessel position and actual time.
Dynamic Keys: SRM Message View
[M5]
[Stop]
Discontinue SRM
Message
Transmission in
180 secs.
[M8]
[Exit]
Return to Vessel
Listing
[M6]
[Repeat]
Repeat
SRM
Message
Transmission
immediately
Sending a further SRM to an Addressed Vessel:
Dynamic Keys: Write Addressed SRM
[M5] [Send]
Send Message
[M8] [Back]
Return
to
Vessel Listing
[M6] [Channel]
Select
Transmission
Channel
[M7] [Channel]
Select
Transmission
Channel
N 1°18' E 0°12' |1> N/A|2>0.00|3>0.10nm
-SRM----SRM----SRM----SRM----SRM----SRM-
MAYDAY,DE,ANDREA DORIA,D11233,1193046,PO
S:N 1
o
19.006'_E 0
o
12.451'_UTC07:31 - F
IRE, EXPLOSION
Repeating SRM in 180 sec...
************** Stop SRM? ***************
----------------------------------------
| Stop | Repeat | |<-Exit
N 1
o
19' E 0
o
13' |1>0.10|2>1.30|3>1.80nm
************ Write Message *************
Addressed SRM 116
SendTo:5004 (DOREEN)
Text:YOUR SHIP IS CLOSEST PLSE COME TO M
Y AID
----------------------------------------
auto/ A / B /A+B
Channel: [*]/[ ]/[ ]/[ ]
----------------------------------------
| Send |
