3.4.7 Display Settings
3.4.8 Graphical Display Settings
N 1 o 21' E 0 o 15' |1>0.10|2>1.30|3>1.80nm
*********** Display Settings ***********
Mode
|
+-[*] Day Min Max
| +---- Brightness:<9> [*********]
| +---- Contrast : 6 [****** ]
|
|
+-[ ] Night Min Max
+---- Brightness: 3 [*** ]
+---- Contrast : 2 [** ]
----------------------------------------
NUM|DayNight| | | Back
N 1 o 46' E 0 o 39' |1>0.10|2>1.30|3>1.80nm
|----------------------------------
| 8 Graphical Display Settings
-----| |
| +- 1. Fairway View Scale
View | +- 2. Fairway View Symbols
| +- 3. Radar View Symbols
-----| +- 4. Other graphical Settings
|
Msg. |
|
-----|
|
Displ|
----------------------------------------
NUM |Select->| | <-Back
