Y1-03-0211 Rev D 43
Mask input:
Scroll the Data Fields with [Enter] and input the UN destination codes as well as the ETA
(estimated time of arrival) data.
Save the new settings by pressing [Save], and return to the Main Menu Screen by pressing
[Exit]. Press [Exit] to return to the Main Menu without saving any changes.
Toggle back to
„input string‟ converts your data to one string
Dynamic Keys: Input of Voyage Related Data
[M5] [Save] Confirm Data Input [M8] [Exit]
Return to Main
Menu
After the Voyage Settings have been input and saved, this screen appears.
[Exit] takes the user back to the Main Menu.
N 1 o 30' E 0 o 24' |1>0.10|2>1.30|3>1.80nm
----------------------------------------
++++++++++++++++++++++++++++++++++++++++
Data saved.
++++++++++++++++++++++++++++++++++++++++
----------------------------------------
| | | | <-Exit
N 1 o 18' E 0 o 12' |1>0.01|2>1.30|3>1.80nm
************* Destination***************
use mask [*]/[ ] input string
UN Country :NL
UN Location :DOR
Fairway section:02552
Terminal code :LEUVE
Fairway hector :00000
ETA(MMDDhhmm) :10/31 10:05
----------------------------------------
| Save | | | Exit
