Y1-03-0211 Rev D 56
f) Inland AIS Configuration / Blue Sign
This screen allows the user to toggle the quality of the speed, course or heading information
received from an external device. These settings are normally set to low.
NOTE: It is highly recommended to keep the settings on low.
Blue Sign:
Toggle the value from to when a Blue Sign switch is connected.
Setting the blue sign can be done by an external hardware switch. Please see the
Installation Manual on how to connect the blue sign - cable 2635 (NAU-B502)
BlueSign Blue Sign no blue sign switch is connected
when a blue sign switch is connected
Dynamic Keys: Inland AIS Configuration
[M5] [Save] Save Settings [M8] [Exit]
Return to
Transponder
Configuration
N48°12' E 16°26' |1> N/A|2> N/A|3> N/Anm
******* Inland AIS Configuration *******
Quality information
Speed : Low
Course : Low
Heading: Low
BlueSign :
----------------------------------------
| Save | | | Exit
