Y1-03-0211 Rev D 29
An LRI has arrived; the NAUTICAST Settings are configured to Manual Mode:
The LRI therefore needs to be manually handled (accepted or rejected)
Dynamic Keys: LRI in the Inbox History (manual mode)
[M5] [OK]
Accept LRI
Interrogation
[M7] [Reply]
Send Addressed
Message to LRI
Sender
[M6] [Reject]
Reject LR
Interrogation
[M8] [Back]
Return to
Messages Menu
g) Inbox History
The Inbox History provides a means to reading incoming messages and alarms. The
messages are listed in chronological sequence. The message type (SRM, ALR or LRI),
Status, Time, Message Text Preview and MMSI Number of sender are shown in this
overview screen.
To select a message navigate with the cursor [Up] or [Down] – the selected message text is
displayed in the text field. The [Back] button takes the user to Messages Menu.
N 1 o 20' E 0 o 13' 1>0.10|2>0.00|3>0.10nm
************** Inbox LRI ***************
LRI 07:44 5004
TEXT TO LRI SENDER CAN BE INPUT HERE
07:44 11/28 ------------------ POS:01/01
LRI 5004
ACK
----------------------------------------
| | | Reply | Back
N 1 o 20' E 0 o 14' ||1>0.10|2>1.30| * 1L
************** Inbox LRI ***************
LRI *07:49 5004
LRI 07:44 5004
07:49 11/28 ------------------ POS:01/02
LRI 5004
(manual mode)
Please acknowledge with OK/Reject!
----------------------------------------
| OK | Reject | Reply | Back
