Y1-03-0211 Rev D 12
Press Save to store the changes.
2
NAUTICAST™ Inland AIS User Interface
2.1
NAUTICAST Keyboard
The NAUTICAST is fitted with a full alphanumeric keyboard, with the following functions:
By pressing any key on the keyboard the letters are addressed.
Number symbols and special characters are addressed by holding down the
shift [] key and simultaneously pressing the chosen key.
The characters ($; %; &; /; (;); <; o ; \ ; [; ]; ) can be reached by holding down the Function
[Fn] key and pressing the chosen key.
2.2
Explanation of the “Cursor Cross”
The Cursor Cross allows navigation within the current
screen [Up] [Down] [Left] [Right].
In addition to the actually displayed [Enter]
button, the
center of the cursor cross always has the Enter functionality.
Soft Keys [M1]
– [M8] Display Safety Keys
Cursor
Cross
Enter Key
Keyboard
Ship Details 12 lines
Or
Menu Structure 14 lines
Navigation Screen
Header (1 or 4 lines)
