Y1-03-0211 Rev D 50
The new User Password configuration has been saved.
b) Region Settings
A Region is a defined area, with specific VHF parameters, which are sent out by Vessel
Traffic Service Stations (VTS), and received via Digital Selective Calling (DSC) or AIS.
The screen shows a list of Regions, and their input sources. When the vessel enters into one
of the pre-defined Regions, the NAUTICAST automatically switches to the relevant Region
Setting. If a Region Number is vacant, then the relevant Region Name Slot is currently
unoccupied.
Tip: For fast Region Selection, press the Region Number on the keyboard and the selected
region is immediately displayed.
Dynamic Keys: Region Settings
[M5] [Select]
Confirm Region
Number Selection
[Back]
Return to Menu
Configuration
[M6] [New] Create New Region
N 1 o 33' E 0 o 27' |1>0.10|2>1.30| * 1A1L
----------------------------------------
++++++++++++++++++++++++++++++++++++++++
Data saved.
++++++++++++++++++++++++++++++++++++++++
----------------------------------------
| | | | <-Exit
N 1 o 18' E 0 o 12' |1>0.10|2>1.30|3>1.80nm
*********** Region Settings ************
..Name....Valid...Source.......DaysOld..
1>Region 1 OK A:AddrChM 2 06:21:59
2>Region 2 OK B:BcastChM 37 09:36:14
3>Region 3
4>Region 4 OK ? N/A N/A
5>Region 5 OK M:OpManual 23 11:02:40
6>Region 6 OK C:AIS_ChAs 10 12:39:17
7>Region 7
8>Region 8 OK D:DSC_Ch70 27 05:56:34
9>Region 9 OK C:AIS_ChAs 9 17:08:46
In use:Region 6
----------------------------------------
NUM| Select->| New | |<-Back
