Y1-03-0211 Rev D
27
e) Confirmation of Broadcast Sent Message
This Confirmation Screen shows that the message was successfully transmitted on the
Broadcast Setting. By pressing [Back] the user automatically returns to the Message Editor
for further Messaging. The [SendTo]
returns the user to the Vessel Listing, with the option of
further Message Writing to individual vessels.
In the case of failed transmission, the following screen appears. In this case, it is
recommended to retransmit the Broadcast Message.
f) Long Range Interrogation
Mobile, and shore-based stations have the ability to interrogate vessels and make requests
for information over the “Long Range Interface”. The interrogated vessel can either reply in
automatic, or in manual mode. The interrogation request is displayed in both modes.
The arrival of a Long Range Interrogation Request is indicated by:
1L on the top right hand corner of the Navigation Screen. The LRI automatically arrives in
the Message Inbox LRI and can be handled from there.
N 1
o
19' E 0
o
13' |1>0.10|2>1.30|3>1.80nm
----------------------------------------
++++++++++++++++++++++++++++++++++++++++
Broadcast Transmission Status
[+] OK, broadcast successful
++++++++++++++++++++++++++++++++++++++++
----------------------------------------
| | Send To | | <-Back
N 1
o
19' E 0
o
13' |1>0.10|2>1.30|3>1.80nm
----------------------------------------
++++++++++++++++++++++++++++++++++++++++
Broadcast Transmission Status
[-] Message could not be sent
++++++++++++++++++++++++++++++++++++++++
----------------------------------------
| | Send To | |<-Back
