Y1-03-0211 Rev D
28
Handling a Long Range Interrogation (LRI)
Default Settings for LRI Requests:
Automatic Mode:
The LRI is automatically dealt with and own vessel data is sent.
Manual Mode:
The LRI needs to be manually handled.
NOTE: The data which may be interrogated via the Long Range Interface can be configured
in Menu 5: Configuration, Submenu 5: Interrogation Settings.
An LRI has arrived;
The NAUTICAST Settings are configured to Automatic Mode:
Dynamic Keys: LRI in the Inbox History (automatic mode)
[M5]
[OK]
Confirms that LRI
has been seen
[M8]
[Back]
Return
to
Message Menu
[M7]
[Reply]
Send
Addressed
Message to LRI
sender
Upon activation of the [OK] button, the user confirms that he has been notified of a current
Transponder system interrogation. This information is useful, as it prevents unknown
interrogation from taking place when the transponder is set in automatic mode.
Upon pressing the [Reply] button, user returns to the Message Editor from where it is
possible to send an addressed message to the LRI sender.
LAT:N 1
o
20.256'ExtSOG:34.6kn * 1L
LON:E 0
o
13.700'ExtCOG:173.0
o
07:44:49
IntGPS: 3D ExtHDT:222
o
Reg6 SRM /B
001/021..ShipName....RNG.BRG..SOG..COG..
LAT:N 48°12.177'IntSOG:0.0kn 02/25/2008
LON:E 16°26.166'IntCOG:0.0° 15:08:29
IntDGPS:3D /B Reg1 ! 3A 2T
BluSign: OFF AISMode: INLAND
012/034..ShipName....RNG.BRG..SOG..COG..
WACHAU [Cl-A] 1.50 320 0.0 208.2
OSB WIEN_____[Cl-A] 1.57 319 0.1 298.4
TWIN CITY LIN[Cl-A] 1.73 319 0.1 220.4
ADMIRAL TEGET[Cl-A] 1.80 319 0.1 214.2
VINDOBONA____[Cl-A] 1.83 319 0.0 224.6>
N 1
o
20' E 0
o
13' |1>0.10|2>1.30| * 1L
************** Inbox LRI ***************
LRI *07:44 5004
07:44 11/28 ------------------ POS:01/01
LRI 5004
(automatic mode)
Please confirm with OK!
----------------------------------------
| OK | | Reply | Back >
