Y1-03-0211 Rev D 34
i)
Inbox of a received “Requested Time of Arrival” (RTA) Message
Upon selection of “7. Lock Reply” in the Message Menu, the received Reply to your ETA –
Message appears. The Message contains:
- The timestamp of this message in the format MM/DD hh:mm.
- The location code of the Lock
- The requested time of arrival at the lock in the format MMDDhhmm (month-day-hour-
minute).
- The status of the lock (operational / not operational).
Dynamic Keys: Broadcast Message Editor
[M8] [Back]
Return to Messages
Menu
j) State / Conditions
This screen provides a means to viewing the current AIS status of all vessels within
receiving range. The information reported is own vessel‟s last AIS contact with the other
vessel in the listing (Time), the Transponder mode (Mod.), the synchronization status (Syn.)
and the total number of vessels being received by each vessel in the listing (RXVe). The
vessel‟s (MMSI) number is also shown on the right hand side of the screen.
N 1 o 22' E 0 o 16' |1> N/A|2>0.00|3>0.10nm
************* Lock Reply ***************
TimeStamp : MM/DD hh:mm
UN Country :
UN Location :
Fairway section:
Terminal code :
RTA(MMDDhhmm) :
Status :
----------------------------------------
| | | | Exit
N 1 o 22' E 0 o 15' |1>0.10|2>1.30|3>1.80nm
********** State / Conditions ***** AIS1
ShipName......Time.Mod.Syn.RXVe..MMSI...
DOREEN 2:07 AU I 1 5004
FINE EAGLE 4:51 AU I 11 5008
SYLVAEPSILON 2:54 AU I 1 5264
ESSOTOKYO 2:11 AU D 2 5776
OLYMPIAHIGHWA 6:44 ?? D 1 354503000
SANEI 5:39 AU I 6 776840000
KATOO 2:58 AU D 3 203375830
OLYMPIA PALAC 6:01 AS D 2 241455470
MINILOG 4:42 AS D 7 234712450
ALIBRAHIMYA 7:40 AS B 3 232834560
TITANIC 0:57 AS I 2 419245790>
----------------------------------------
| | | | Back
