Y1-03-0211 Rev D
39
The password query field appears. Input new User Password and press [Enter].
Select Submenu 1 “General Settings” with cursor button [Up] & [Down] by pressing No. 1
on the keyboard.
Scroll the Data Fields with [Enter] and input own vessel data. Enter a draught in meter and
air-draught value in centimetre (cm = m/100) as well as the correct navigational status
setting.
Save the new settings by pressing [Save], and return to the Main Menu Screen by pressing
[Exit]. Press [Back] to return to the Main Menu without saving any changes.
N 1
o
31' E 0
o
24' |1>0.01|2>1.30|3>1.80nm
----------------------------------------
++++++++++++++++++++++++++++++++++++++++
User password protected!
Please enter user password:
++++++++++++++++++++++++++++++++++++++++
----------------------------------------
| Enter | | | Exit
++++++++++++++++++++++++++++++++++++++++
N 1
o
18' E 0
o
12' |1>0.01|2>1.30|3>1.80nm
|----------------------------------
| 3. Voyage Settings
-----| |
| +- 1. General Settings
View | +- 2. Cargo / Voyage
| +- 3. Persons on Board
-----| +- 4. Destination
|
Msg. |
|
-----|
|
Displ|
|
----------------------------------------
NUM|Select->| | |<-Back
