CYCLE TIME



to

2

seconds

This cycle time functions like the O1 Output Cycle Time but allows

independent cycle time for cooling. A setting of zero will keep output O2 off.

RELATIVE GAIN



to

1

This defines the gain of the cooling relative to the heating. It is generally set

to balance the effects of cooling to that of heating. This is illustrated in the Heat/

Cool Relative Gain Figures. A value of 0.0 places the cooling output into On/

Off Control.

2

DEADBAND/OVERLAP



to



This defines the overlap area in which both heating and cooling are active

(negative value) or the deadband area between the bands (positive value). If a

heat/cool overlap is specified, the percent output power is the sum of the heat

power (O1) and the cool power (O2). If Relative Gain is zero, the cooling

output operates in the On/Off Control Mode, with the On/Off Control

Hysteresis  in Output Module 2 becoming the cooling output hysteresis.

The function of Deadband is illustrated in the Control Mode Explanations. For

most applications, set this parameter to 0.0 prior to starting Auto-Tune. After

the completion of Auto-Tune, this parameter may be changed.

7.5 module 5 - C

ooling

(S

eCondAry

) p

ArAmeterS

(

5-O2

)

CYC2

db-2

gAN2

COOLING

CYCLE

COOLING

RELATIVE

HEAT/COOL

DEADBAND/

5-O2

CNFP

OVERLAP

TIME

GAIN

PARAMETER MENU

To enable Cooling in Heat/Cool applications, the Alarm 2 Action must first

be set for Cooling. (For P16 Controllers, the cooling output is sometimes

referred to as secondary output.) When set to cooling, the output no longer

operates as an alarm but operates as a cooling output. The O2 terminals are the

same as A2, however a separate O2 annunciator indicates Cooling Operation.

Cooling output power ranges from -100% (full cooling) to 0% (no cooling,

unless a heat/cool overlap is used). The Power Limits in Output Module 2-OP

also limit the cooling power. In applications requiring only a Cooling output,

the main 01 output should be used.

2

2

1

2

TEMPERATURE

COOL

HEAT

SETPOINT

-100%

O2

+100%

O1

2X PROPORTIONAL

BAND

OUTPUT

POWER ( )

%

O1

+100%

SETPOINT

DEADBAND

NEGATIVE VALUE

POWER ( )

OUTPUT

%

COOL

RELATIVE GAIN = .5

.5

1

2

RELATIVE GAIN

O2

-100%

TEMPERATURE

HEAT

TEMPERATURE

HEAT

SETPOINT

-100%

O2

+100%

O1

DEADBAND

POSITIVE VALUE

POWER ( )

OUTPUT

%

RELATIVE GAIN

2

1

.5

RELATIVE GAIN = .5

COOL

HEAT/COOL RELATIVE GAIN FIGURES

Heat/Cool Deadband = 0

Heat/Cool Deadband < 0

Heat/Cool Deadband > 0
