5
M
ODEL
DP5T - T
HERMOCOUPLE AND
RTD I
NPUT
A
CCESSORIES
O
THERMOCOUPLE AND RTD INPUTS
O CONFORMS TO ITS-90 STANDARDS
O TIME-TEMPERATURE INTEGRATOR
DP5T SPECIFICATIONS
READOUT:
Resolution: Variable: 0.1, 0.2, 0.5, or 1, 2, or 5 degree
Scale: F or C
Offset Range: -19,999 to 99,999 display units
THERMOCOUPLE INPUTS:
Input Impedance: 20 M Ω
Lead Resistance Effect: 0.03 µV/ohm
Max. Continuous Overvoltage: 30 V
RTD INPUTS:
Type: 3 or 4 wire, 2 wire can be compensated for lead wire resistance
Excitation current: 100 ohm range: 165
µA
10 ohm range: 2.6 mA
Lead resistance: 100 ohm range: 10 ohm/lead max.
10 ohm range: 3 ohms/lead max.
Max. continuous overload: 30 V
DIRECT READOUT:
Input range: -10 to 65 mV
0 to 400 ohms, high range
0 to 25 ohms, low range
Display range: -19999 to 99999
STANDARD
***
ACCURACY*
(0 to 50°C)
ACCURACY*
(18 to 28°C)
RANGE
no official
standard
0.9°C 0.4°C -100 to 260°C
10 ohm Copper
alpha = .00427
INPUT TYPE
no official
standard
0.5°C 0.2°C -80 to 260°C
120 ohm Nickel
alpha = .00672
no official
standard
1.6°C 0.4°C -200 to 850°C
100 ohm Pt
alpha = .003919
IEC 751 1.6°C 0.4°C -200 to 850°C
100 ohm Pt
alpha = .00385
0.20% of reading
+ 0.007 Ω
0.04% of reading
+ 0.005 Ω
0 to 25 Ω
(1 M Ω res.)
Direct
10 ohm range
0.12% of reading
+ 0.05 Ω
0.02% of reading
+ 0.04 Ω
0 to 400 Ω
(10 M Ω res.)
Direct
100 ohm range
ACCURACY*
(0 to 50°C)
0.12% of reading
+ 5 µV
0.02% of reading
+ 4 µV
-10 to 65mV
(1 µV res.)
Direct
mV range
ACCURACY*
(18 to 28°C)
RANGE INPUT TYPE
WIRE COLOR
INPUT
TYPE
RANGE
ACCURACY*
(0 to 50°C)
STANDARD
ANSI BS 1843
T
-200 to 400°C
-270 to -200°C
1.2°C
**
2.1°C
ITS-90
(+) blue
(-) red (+) white
(-) blue
E
-200 to 871°C
-270 to -200°C
1.0°C
**
2.4°C
ITS-90
(+) purple
(-) red (+) brown
(-) blue
J -200 to 760°C 1.1°C 2.3°C ITS-90
(+) white
(-) red (+) yellow
(-) blue
K
-200 to 1372°C
-270 to -200°C
1.3°C
**
3.4°C
ITS-90
(+) yellow
(-) red (+) brown
(-) blue
R -50 to 1768°C 1.9°C 4.0°C ITS-90
no
standard (+) white
(-) blue
S -50 to 1768°C 1.9°C 4.0°C ITS-90
no
standard (+) white
(-) blue
B
100 to 300°C
300 to 1820°C
3.9°C
2.8°C 5.7°C
4.4°C
ITS-90
no
standard no
standard
N
-200 to 1300°C
-270 to -200°C
1.3°C
**
3.1°C
ITS-90
(+) orange
(-) red (+) orange
(-) blue
C
(W5/W26)
0 to 2315°C 1.9°C 6.1°C
ASTM
E988-90***
no
standard no
standard
*After 20 min. warm-up. Accuracy is specified in two ways: Accuracy over an
18 to 28°C and 15 to 75% RH environment; and Accuracy over a 0 to 50°C and 0
to 85% RH (non condensing) environment. Accuracy specified over the 0 to 50°C
operating range includes meter tempco and ice point tracking effects. The
specification includes the A/D conversion errors, linearization conformity, and
thermocouple ice point compensation. Total system accuracy is the sum of meter
and probe errors. Accuracy may be improved by field calibrating the meter readout
at the temperature of interest.
** The accuracy over the interval -270 to -200°C is a function of temperature,
ranging from 1°C at -200°C and degrading to 7°C at -270°C. Accuracy may be
improved by field calibrating the meter readout at the temperature of interest.
*** These curves have been corrected to ITS-90.
ACCURACY*
(18 to 28°C)
UNITS LABEL KIT (PAXLBK) - Not required for DP5T
Each meter has a units indicator with backlighting that can be customized
using the Units Label Kit. The backlight is controlled in the programming.
Each DP5T meter is shipped with °F and °C overlay labels which can be
installed into the meter’s bezel display assembly.
