Red Lion DP5T - Manual (Page 2)

2
Ordering Information . . . . . . . . . . . . . . . . . . . 2
General Meter Specifications. . . . . . . . . . . . . 3
Universal DC Input Panel Meter . . . . . . . . . . 4
Process Input Panel Meter . . . . . . . . . . . . . . 4
Thermocouple and RTD Input Meter . . . . . . . 5
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing the Meter . . . . . . . . . . . . . . . . . . . . 6 Setting the Jumpers . . . . . . . . . . . . . . . . . . . 6
Wiring the Meter . . . . . . . . . . . . . . . . . . . . . . 7
Reviewing the Front Buttons and Display . . . 9
Programming the Meter . . . . . . . . . . . . . . . 10
Factory Service Operations . . . . . . . . . . . . . 17
Parameter Value Chart . . . . . . . . . . . . . . . . 19
Programming Overview. . . . . . . . . . . . . . . . 20
T
ABLE
O
F
C
ONTENTS
O
RDERING
I
NFORMATION
DP5 0 0
D - DC Volt/Current Input
P - Process Input
T - Thermocouple and RTD Input
0 - Red LED Display
0 - 85 to 250 VAC
1 - 11 to 36 VDC, 24 VAC
Meter Part Numbers
Accessories Part Number
PAXLBK10 Units Label Kit Accessory (Not required for DP5T) PAXLBK Accessories
TYPE PART NUMBERS DESCRIPTION MODEL NO.
