-49-
TROUBLESHOOTING GUIDE (Cont’d)
PROBLEMS POSSIBLE CAUSE REMEDIES
PROCESS, BATCH, TOTAL, PEAK, OR
VALLEY VALUES WILL NOT RESET WHEN
A MANUAL RESET IS PERFORMED 1. User input NOT properly programmed. 1. Verify programming in “Program User Module”.
CANNOT ENTER INTO
PROGRAMMING MENUS 1. Front panel disabled. 1. Check “Front Panel Accessible Functions With
Program Disable” section in manual.
PRESETS, COUNTER LOAD, OR
SCALE FACTORS CAN BE VIEWED
BUT NOT CHANGED 1. Front panel disabled. 1. Verify programming in “Program Options
Module” sub-menu Operator Access.
2. Check “Front Panel Accessible Functions With
Program Disable” section of manual.
UNIT COUNTS WHILE RESET IS ACTIVATED 1. User input Reset mode set for Momentary reset. 1. Program User input to a Maintained reset.
OUTPUT WILL NOT RESET 1. Output assigned to wrong display (Count or Rate). 1. Verify programming in “Program Outputs Module”.
2. Reset with count disabled (Program Outputs Module). 2. Verify programming in “Program Outputs Module”.
3. User input NOT properly programmed. 3. Verify programming in “Program User Module”.
NO RATE INDICATION 1. No signal at input A. 1. Check sensor connections.
a. Verify power to sensor.
2. Type of input signal selected incorrectly. 2. Check DIP switch setting on side of unit.
3. Rate Scale factor and/or Rate Scale Multiplier
too small.
3. Check scale factor value and scale multiplier values.
