Red Lion LEGEND - Manual (Page 31)

LGB FACTORY SETTINGS (Cont’d)
OUTPUTS (Cont’d):
Output 3:
Assigned TO BATCH
Phase + PHASE
Type TIMED
Time Delay 0.1
Status [email protected]
Reset w/Cnt ENABLED
Output 4:
Assigned TO BATCH
Phase + PHASE
Type TIMED
Time Delay 0.1
Status [email protected]
Reset w/Cnt ENABLED
DISPLAYS:
Display 1:
Line 1 RATE-MNE
Line 2 RATE-VAL
Display 2:
Line 1 PEAK-MNE
Line 2 PEAK-VAL
Display 3:
Line 1 VALI-MNE
Line 2 VALI-VAL
Display 4:
Line 1 PRC- MNE
Line 2 PRC- VAL
Scroll Speed NONE
COMMUNICATIONS:
Baud rate 1200
Parity ODD
Address 00
Xmit Delay 0.100
PRINT OPTIONS:
Rate YES
Peak NO
Valley NO
Process YES
Batch YES
Total YES
Scale Factors NO
P1 & P2 NO
P3 & P4 NO
Counter Load NO
Mnemonics YES
OPTIONS:
Operator Access:
Scale Factors YES
P1 YES
P2 YES
P3 YES
P4 YES
Counter Load YES
Preset Tracking:
P1 trac P2 NO
P3 trac P4 NO
