HMP230 SERIES
Appendix 1: Serial commands
M210225en-B
86
ACAL
Calibrating the analogue outputs
Disconnect the security lock jumper!
ACAL
Calibrates the outputs selected on channels 1 and 2. The output is measured
and the measured values (mA or V) entered as calibration coefficients.
For example, calibrating the outputs when 0...10 V signal has been selected on
both channels (set with AMODE command):
>ACAL
Ch1
U1
(V
) ?
0.123
Ch1
U2
(V
) ?
9.98
Ch2
U1
(V
) ?
0.120
Ch2
U2
(V
) ?
9.98
L
Outputting linear correction coefficients
L
With the help of command L the user can check how the transmitter has been
adjusted after it has been calibrated at the factory.
>L
RH
offset
: 0.000
RH
gain
: 1.000
Tsoffset : 0.000
Ts
gain
: 1.000
LI
Entering linear correction coefficients
Disconnect the security lock jumper!
LI
The LI command is one way of calibrating the transmitters.
>LI
RH
offset
: 0.000
?
-.6
RH
gain
: 1.000
?
Ts
offset
: 0.000
?
Ts
gain
: 1.000
?
.4
The factory settings are offset 0 and gain 1. The transmitter can be returned to
its factory calibration by giving these values.
