Displaying Weather Variables
16
Current Weather Mode Commands
Select a weather variable to display its data on the screen if it isn’t already visible, or to graph
the data available for that variable.
Weather variables are selected via the console command keys:
•
If the variable is printed on a key, press the key to select the variable.
• The same field can display multiple values for each variable. Press the variable key to
scroll through all the values
• Multiple variables may share the same field on the display.
Wind chill, dew point, heat index share the
same field in Current Weather Mode
• If a variable is printed above or below a key, first press and release 2ND, then quickly
press the key below the printed variable to select that variable.
After pressing 2ND, the icon displays on the screen for eight
seconds. Key secondary functions are enabled during this time. The
keys return to normal operation after the icon disappears.
• Select a variable and press WxCEN to display information
pertinent to the selected variable in the Weather Center. Continue
to press WxCEN to scroll through all the information available for the
variable.
• You can also select any variable currently displayed on the LCD screen
using the navigation keys. Press the + key to move the selection arrow up
the screen. Press the - key to move it down the screen. Push the < key to
move it left and push the > key to move it right.
Displaying Weather Variables
The variables are arranged below in the order they are viewed on the console screen; left to
right, top to bottom, starting with Time and Date.
TEMP HUM WIND RAIN BAR
S
SE SW
MPH
WIND
in/hr
RAIN RATE CHILL
DEW HEAT
F
F F
HEAT DEW CHILL ET
UNITS CLEAR SET ALARM SETUP
TEMP HUM WIND RAIN BAR LIGHT
GRAPH HI/LOW TIME W
X
C
EN
2ND DONE
2ND
2
nd
2ND
W
X
C
EN
