13
Mounting an Envoy in the Heavy Duty Solar
Power Kit (12 Ah battery, #6612)
Inside the Heavy Duty Solar Power Kit shelter, you may install:
• An Envoy8X
• A cabled Weather Envoy
• A wireless Weather Envoy where low light or poor conditions require extra power.
Note: If using the Heavy Duty Solar Power Kit to power a cabled Vantage Pro2 console, or a
wireless Vantage Pro2 or Vantage Vue console that requires extra power, you will need to
install the console in a Universal Shelter (product number 6618) and connect it to the
Heavy Duty Solar Power Kit. See Using the Solar Power Kit or Heavy Duty Solar Power
Kit with a Universal Shelter (page 17).
Mounting an Envoy8X (or Weather Envoy) in a Heavy Duty
Solar Power Kit
1. Remove all packaging material. (Don’t forget the cardboard behind the
battery.)
2. Unplug the power cable from the jack closest to the back on the charging
circuit.
Console/Envoy Power
Battery power
Solar power
