12
7. On the back wall of the shelter, look for the embossed outline of an Envoy and
the screw holes marked “E”
8. Insert the two ½'' #6 screws into the marked holes. The depth of the hole has
been specifically designed so that the screw will “bottom out” at the correct
depth. Do not overtighten.
Note: You may need to adjust the screw height for proper fit.
9. Point the Envoy’s antenna downward. Guide the two keyholes on the back of
the Envoy over the two screws and pull the console downward to lock in
place.
10. Plug the power cable into the Envoy. Use your PC to set up the Envoy as
shown in your Weather Envoy Manual.
11. Close and lock the shelter.
E
E
VV VV
VP2 VP2
ENVOY Vantage VUE Vantage PRO2
Vantage VUE
TEMPERATURE
HUMIDITY
BAROMETRIC
PRESSURE
RAINFALL
WEATHER
CENTER
