9
7. On the back wall of the shelter, look for the embossed outline of a Vantage Vue
console and the screw holes marked “VV.”
8. Insert the two ½'' #6 screws into the marked holes. The depth of the hole has
been specifically designed so that the screw will “bottom out” at the correct
depth. Do not overtighten.
Note: You may need to adjust the screw height for proper fit.
9. Remove the kickstand from the console. Guide the two keyholes on the back of
the console over the two screws and pull the console downward to lock in
place.
10. Plug the console power cable into the console. Follow the console setup
procedures in your Vantage Vue Console Manual.
11. Close and lock the shelter.
E
E
VV VV
VP2 VP2
ENVOY Vantage VUE Vantage PRO2
N
S
W E
NE
SE
NW
SW
WIND
am
INSIDE OUTSIDE
RAIN RATE CHILL
in/hr
F F
F
in
Vantage VUE
TEMPERATURE
HUMIDITY
BAROMETRIC
PRESSURE
RAINFALL
WEATHER
CENTER
