AMT Datasouth 600 User Manual
Page 67
User Manual
65
ITEM
PART NO.
DESCRIPTION
QTY
DETAIL
95
47.R4005.001
WASHER2
2
C
96
33.R4020.001
BRACKET -SPRING2
1
D
97
42.R4023.001
BUSH-RIBBON
1
D
98
33.R4019.001
BRACKET-ADJ
1
C
99
35.R4001.002
SHAFT-HOLDER1 V2
1
C
100
88.12301.C06
WASHER-SPRING
2
C
A
86.1A324.4R0
SCREW M3X4 BLACK
6
C,D
B
86.VA824.4R0
SCREW T3X4 BLACK
13
C,D
C
86.VA324.6R0
SCREW T3X6 BLACK
27
C,D
D
86.AA324.6R0
SCREW I3X6 (T) BLACK
7
C,D
E
86.5A524.5R0
FLAT HEAD
4
C
F
86.VG524.6R0
SCREW T3X6 WASHER
2
D
G
86.1A324.6R0
SCREW M3X6 BLACK
1
D
H
88.81241.806
E -RING #5
5
C,D
I
88.81241.606
E -RING #3
14
C,D
J
88.81241.A08
E -RING #6
2
C
K
88.81241.406
E -RING #4
2
C
L
86.VA324.8R0
SCREW T3X8
6
D
M
86.VA424.370
SCREW T3X37
2
NOT SHOWN
N
86.1A522.2R0
SCREW M2X2 NI
2
NOT SHOWN
O
86.AA522.6R0
SCREW T2X6
4
NOT SHOWN
P
86.1A524.8R0
SCREW M3X8 NI
1
C
