User Manual 29
Printing the Configuration Label
Important information:
§ The configuration label indicates the current setting and parameters of the printer.
Some of the items displayed in this label are:
Current Firmware revision (Top line of the label).
RS-232 parameters,
Media type (DT/TT),
Label Count,
Media Sensor Level,
Resident font types,
etc.
§ Following printing of the configuration page the printer may be in a diagnostic
(hexadecimal) mode. To exit the diagnostic mode, turn the power off.
§ The printed configuration will be different depending upon the emulation loaded, and
current value settings.
Procedure for printing a Configuration Label.
1. Power off the printer.
2. Make sure that the installed media is 4 inches wide and 20 inches in length (five 4x4
labels or four 4x6).
The printer will first do a label calibration (12 inches in length), then print a configuration label
(approximately 5 inches in length).
3. Verify that the media is properly loaded and routed as detailed in Loading Media
Section.
4. While pressing and holding the FEED key, power on the printer.
5. Continue to hold the FEED key until the printer begins to print the configuration label,
then you may release the FEED key.
