User Manual 63
ITEM PART NO. DESCRIPTION QTY FIGURE
49 35.R4008.002 SHAFT2-CHASSIS 1 C
50 32.R4006.001 GEAR 48T 1 C
51 33.R4005.002 BRACKET-SWITCH (R ) 1 C
52 34.R4017.001 SPRING-BUTTON (R) 1 C
53 33.R4008.001 BRACKET-SHAFT (R) 1 C
54 34.R4011.004 SPRING-TPH 2 C
55 33.R4003.007 BRACKET-TPH V7 1 C
110478.2 KIT, 200 DPI PRINTHEAD 1
56 110478.3 KIT, 300 DPI PRINTHEAD 1 C
57 110478.7 KIT, RIBBON SENSOR 1 D
58 33.R4011.003 COVER-TPH 1 C
59 35.R6001.001 SHAFT-TPH (L) 1 C
60 35.R4007.002 SHAFT1-CHASSIS 1 C
61 39.R4003.001 COVER-A 1 B
62 110948 GUIDE, MEDIA SUPPLY 2 B
63 110947 SPINDLE, MEDIA SUPPLY 1 B
64 34.R6001.001 SPRING-SHAFT (R) 1 C
65 35.R6002.001 SHAFT-TPH (R) 1 C
67 42.R4007.002 BUTTON-TOP (R) 1 B
68 42.R4006.002 BUTTON-TOP (L) 1 B
69 42.R4008.001 BUTTON (3-KEY) 1 B
70 55.R4001.011 PANEL BOARD 1 B
71 33.R4006.001 BRACKET-PEELER 1 D
72 33.R4014.002 BRACKET-CONNECTOR 1 D
